Semi-Enclosed Exchangeable Platform — CHYLASER 1 / 2
Sheet Laser Cutting Series

Semi-Enclosed Exchangeable Platform

The Perfect Balance of Safety, Efficiency, and Value.

  • Semi-Enclosed Safety Design
  • Fast Table Exchange
  • Cost-Effective Solution
  • Stable Industrial Performance
Learn more about these advantages ↓
Available Models
HYCA-30153000 × 1500 mmHYCA-40204000 × 2000 mmHYCA-60206000 × 2000 mmHYCA-60256000 × 2500 mm
See full specifications ↓
Get a Quote WhatsApp
Product Advantages

The Perfect Balance of Safety, Efficiency, and Value.

Balanced Protection & Accessibility
Semi-Enclosed Safety Design

Balanced Protection & Accessibility

Provides effective dust and spark containment while maintaining access , ensuring a safer working environment.

Reduce Loading Time
Fast Table Exchange

Reduce Loading Time

Dual exchange tables significantly shorten loading time, improving overall production efficiency and workflow continuity.

Better Value for Investment
Cost-Effective Solution

Better Value for Investment

Delivers strong performance and safety features at a more competitive price compared to fully enclosed models, maximizing cost efficiency.

Efficient & Reliable Operation
Stable Industrial Performance

Efficient & Reliable Operation

Designed for continuous cutting with stable performance, making it ideal for efficient and practical industrial production needs.

Note: Images are for reference only. Actual product may differ slightly from images.

Technical Specifications

The models shown below represent only a selection of our product portfolio.More configurations and customized solutions are available to meet different application needs and production requirements.

ParameterHYCA-3015HYCA-4020HYCA-6020HYCA-6025
Max. Cutting Sheet Size(L × W)3000 × 15004000 × 20006000 × 20006000 × 2500
X-Axis Travel (mm)1520202020202520
Y-Axis Travel (mm)3020402060206020
Z-Axis Travel (mm)300300300300
X, Y Axis Positioning Accuracy (mm)±0.05±0.05±0.05±0.05
X, Y Axis Repeatability (mm)±0.03±0.03±0.03±0.03
Max. Positioning Speed (X/Y Axis) (m/min)70-13970-13970-13970-139
Max. Acceleration (X/Y Axis) (G)2.02.02.02.0
Overall Dimensions of Main Machine (L × W × H) (mm)≈ 8600 × 2820 × 2300≈ 10650 × 3320 × 2300≈ 15000 × 3340 × 2300≈ 15000 × 3850 × 2450

Specifications are subject to laser power and configuration options. Contact our engineers for a detailed technical proposal tailored to your materials and production volume.

Need Something Different?

If our standard models don't perfectly match your production needs, our engineering team can customize a solution built around your materials, workflow, and volume.

Request Custom Solution
